Product Details:
Specifications:
1.square linear guide , rack and pinion for three axis
2.spindle :3KW
3.vacuum pump
4.CE
Description:
wood cnc router engraving machin DL-1325
Specification:
Model
cnc wood engraving machine DL-1325
Working Zone: (X Y Z)
1300×2500×200mm
Table Size (W×L)
1420×2780mm
Resolution
<0.003mm
Cutting Accuracy
± 0.02/300mm
Repositioning Accuracy
±0.01mm
Axis Drive System (X Y Z)
square linear guide , rack and pinion for three axis
Drive Type
stepper motor
Spindle
3.0 KW liquid-cooled with 24, 000rpm, VFD
Max. Working speed
10, 000mm/min
Collets Type
3.175/46mm
Command Code
G*.u00*.mmg*nc., HPGL
Operational System Software
Type 3/Artcam/Castmate/Wentai
Control System
NC studio
Interface
PCI/USB
Max. Power Consumption
3.2KW
Voltage
AC220V±10%/50~60Hz
Standard Work Surface
Aluminum profiles
Weight
550kg±10%
Warranty
12 Months (spindle: 6 months)
cnc wood engraving machine
15*15cm width , 1cm thickness square steel tube
three axis used HIWIN 25mm square linear guide , rack and pinion
Applications
Advertisement: engraving and cutting of various
labels and number plate, marble, etc for artistic effects on
materials including marble, brass, steel, and other metallic
material.
Crafts: engraving characters of any language and
patterns on gifts and souvenirs, primitive processing and shaping
of artistic crafts, and stiletto.
Moulding: engraving delicate letter and flower
pattern, primitive and fine processing of the small mould.
Architectural models: engraving fine window,
fencing and wall patterns, etc.
Seal: engraving seals and medal on materials such
as buffalo horn, wood etc.
Label: engraving character, number, and other
pattern on label for products and on product directly.
Wood processing: processing density board,
stiletto for surfing board, processing of marbles, cabinet and
furniture
Mark:
We can produce the machine as client's requirements.
1.The table size could be changed as client's requiremens
2.Single-spindle could be increased as multi-spindle
3.Drive model:Step motor or servo motor optional
4.Spindle:Air cooled or water cooled optional
5.Guide rail:linear guide rail or squared linear guide rail optional
6.Optinal Parts: oil lubricate service, dust collector device, DSP handle control rotary device and so on.
wood cnc router engraving machine DL-1325
