Gear transmission LXM1530 mach 3 system 4 axis cnc router machine for acrylic plastic

Machine parameter

Description parameter

XYZ working area 1500*3000*200mm

XYZ travel positioning accuracy 0.05mm

XYZ repositioning positioning accury 0.05mm

Table surface Bakelite sheet

grantry steel

drive system X-Y axis Rack actuation

drive system Z axis Ball screw

Spindle power 3.0KW water cooling spindle

Max velocity 50m/min

Max working speed 25m/min

Spindle speed 0-24000rmp

work mode stepper motor (optional servo motor)

Working voltage AC380V/50HZ

Command language G code

Interface USB

Operating system DSP

Flash memory 128

X-Y resolution 0.025mm

Software environment artcam, type3/ucancam is optional

Running environment Temperature:0-45

Paking size 3750*2500*2000mm

Net weight 1300 kg

Gross weight 1500 kg


1 , Adopt linear-square orbit , whole machine is welded with seamless steel structure,can bear heavy loading

2 , Three axes adopt high precision square orbit , X and Y axes adopt rack and pinion transmission , fast working , high efficiency and low cost ,  Z axis adopts ball screw,with high precision and long life time

3 , High power spindles have constant power , low noises and super strong cutting force , which improve workingefficiency greatly

4 , Famous brand drivers and motors have characteristics such as powerful strength , fast processing speed

5 , Compatible with Type3 , Ucancam , Artcam , and other software of CAD/CAM

6. High power inverter-drive spindle cooled by water , Also can chose air cooled spindle

Machine Application

Furniture , wooden doors , cabinets , plate , office and wood furniture , table , chair , doors and windows

The wood products , Voice box , game cabinets computer tables , sewing machines table , instruments

Plate processing , insulation part , plastic chemical components , PCB , inner body of car , bowling tracks , stairs , anti-bate board , epoxy resin , ABS PP , Pe and other carbon mixed compounds

Decorate industry , Acrylic , PVC , MDF , artificial stone , organic glass , plastic and soft metals such as copper . aluminum plate engraving and milling processing.

Machine photo

Our service

1 Lifetime maintenance free of charge.
2 Free training course at our plant.
3 We will provide the consumable parts at an agency price when you need replacement.
4 24 hours on line service each day, free technical support.
5 Machine has been adjusted before delivery , operation disk was included. If there is also any questions, pls kindly tell me
6 24 months quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge when if there is any problem during the warranty period.
