Standard configuration:
1300*2500*200mm effective work area(can be customized) 3.0kw Italy HSD air cooling spindle(world top brand) 3.7kw Taiwan DELTA inverter(world top quality) DSP control,with hand held controller Taiwan HIWIN 20# (or25#)square linear guide Helical rack transmission for X,Y axis,powerful and stable Taiwan TBI ball screw transmission for Z axis,most accurate precision Vacuum & T-slot working table Water mist cooling sprayer for option(for metal working) Manual lubrication system Tool sensor calibration Japan OMRON limit switch Shanghai Cardiff cable,highly flexible,fire resistantParameter
X,Y,Z Working Area 1300x2500x200mm(Can be customized)
X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
X,Y,Z Repositioning Accuracy ±0.03mm
Table Surface Vacuum and T-slot working table
Frame Welded Structure
X, Y Structure Helical rack, Taiwan HIWIN Rail Linear Bearings
Z Structure Taiwan HIWIN Rail Linear Bearings and Ball Screw
Max. Power Consumption (Without Spindle) 3.2Kw
Max. Rapid Travel Rate 33000mm/min
Max. Working Speed 25000mm/min
Spindle Power 3.0kw Italy HSD air cooling spindle
Spindle Speed 0-18000RPM
Drive Motors YAKO 2811 big driver
Working Voltage AC380V/50/60Hz,3PH (Option: 220V)
Command Language G Code
Operating System DSP handle controller
Computer Interface USB
X,Y Resolution <0.01mm
Software Compatibility Type3/Ucancam/Artcam
Running Environment Temperature 0 - 45 Centigrade
Relative Humidity 30% - 75%
Application:
Woodworking: three-dimensional wave board processing, furniture like solid wood door, kitchen cabinets, wardrobe cabinets, tables, beds, computer desk and cylinders like table legs, sofa legs, wooden craft, paint door, screen, craft fan window processing, shoe polisher, game cabinets and panel, mahjong table, auxiliary processing .
Advertising industry: advertising sign, logo making, acrylic cutting, plastic molding, a variety of materials advertising the production of decorative product.
Mold Industry: engraving wood, foam, EPS, copper, aluminum mold, as well as artificial marble, sand, plastic sheeting, PVC pipe, wood and other non-metallic mold.
Other Industry: a variety of large-scale relief sculpture, shadow carving, widely used in the craft industry.
Product Image
About Jinan Blue Elephant CNC Machinery Co.,Ltd
Jinan Blue Elephant CNC Machinery, the professional CNC router and laser engraving machine manufacturer in China. Our machines including ATC CNC router, wood CNC router, stone CNC router, metal CNC router, EPS CNC router , 4 axis CNC router, 5 axis CNC router, plasma cutting machine, laser engraving and cutting machine. We are located in Jinan City, Shandong Province.
The basement of cnc router machine.with convenient transportation access. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction.
Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.
