Rigid Structure Desktop CNC 5 Axis Router for Three Dimensional Sculpture Process
Features:
1. With OSAI numerical control system, the machine is of high speed and high machining accuracy. the Germany original rotating arm ensure the accuracy and strength of the machine.
2. Z-axis travel can be heightened to 2.1 meters, so it is very suitable for processing large-scale three-dimensional surface.
The intelligent processing cross-border protection function can prevent the excessive process caused by mechanical collision.
3. Diversified control processing speed can control the working speed, traveling speed and dropping tool speed, and it improves the quality and efficiency greatly.
Applicable industries
1. Mold industry: Various large metalloid moulds, especially suitable for automotive foam mold, wooden ship model, wooden model aviation, rail wooden mold and wooden mold train.
2. Instrument industry: 3D surface engraving and shape cutting of large-scale instruments.
Standard Configuration:
X axis
2500mm, Ball screw motion
Y axis
2500mm, Ball screw motion
Z axis
200mm, Ball screw motion
Working speed
15m/min
Table material
Aluminum
Table fix
Vacuum absorption
Vacuum pump power
5.5kw
Rail
Taiwan Hiwin35
Spindle
9.0kw 5 axis HSD air cooling
Spindle speed
24000r/min
Motor
Japan Yaskawa servo motor
Motor power
1.3kw
Operation system
Italy OSAI CNC system
Process precision
0.05mm
Automatic tool changer
Yes
Automatic lubrication system
Yes
Italy HSD 5 axis spindle head
Taiwan Hiwin Ball Screw
Detail advantage :
1: Raw material, we adopt thick walled tube frame construction for the machine
select steel rigidity through professional test
2: precise market position,we design the machine for woodworking mould industry
offer expert andvice and solution for your production
3: passionate engineer,have many years education and work experience
they average age more than 50. all quality products up to the best people
Product Image
About JBT INTELLIGENT MACHINE LIMITED
JBT design and manufactures 3axis CNC and 5axis CNC routers and large format CNC machining centers. With 20 years of innovation, custom engineering and industry experience as an original equipment manufacturer(OEM).
DMS serves almost every industry, especially aerospace, automotive, JBT CNC routers are typically used on materials such as composites,aluminum,plastics,wood and foams
We manufacture industry-quality CNC routers-addressing the need in the market for a cost-effective,industrial CNC machining solution without sacrificing on quality or reliability.
