5'x10' CNC Woodworking Machine with vacuum clamp table
Model: W1530VC
This woodworking CNC router is equipped with vacuum suction table and T slot clamp table. You can hold the big workpiece by vacuum suction, and hold the small workpiece by T slot clamps. Also using clamps holding when doing relief carving can save electricity power and save money.
CNC Router 1530 Woodworking Features:
1. Whole cnc router 5 x 10 is welded with seamless steel structure and is processed by high temperature tempering treatment and vibrating stress relief (VSR) to relief residual stress. The stability is excellent, not easy to be deformed.
2. The router machine woodworking adopts gantry movement. It can process any kinds of materials freely.
3. Three axes adopt Taiwan Hiwin high precision square orbit; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost; Z axis adopts imported ball- screw, high precision and long life time.
4. Well compatibility: CAD/DAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
5. Has the function of re-carving after break point and power failure.
6. Has the function of forecasting process time.
7. Adopting advanced DSP system with USB interface, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
8. Perfect lubricating system makes maintenance much easier.
9. Has duct-collect function. It will clean up the carving residuum and make the operations tidier and more convenient.
10. Advanced design of the machine make sure strong cutting and guarantee the engraving precision.
11. Vacuum table with 6 vacuum zones, which can suck different size materials tightly. It is also convenient for the user to fix the materials by clamp.
12. Adopting air cooling system, powerful and can work well in cold weather.
CNC Router Woodworking Applicable industries:
Wood processing: processing of various furniture such as door, window, cabinet, crafts, screen, slat wall and so on.
Advertisement: engraving and cutting various labels and number plate.
Art craft: engraving characters of any languages and graphics on gifts and souvenirs.
CNC Woodworking Router Applicable materials:
Wood, aluminium board, plastic, density board, wave board, glass, PVC, acrylic, crystal, light marble and other nonmetal materials and light metal materials.
CNC Router for Woodworking Processing effect:
It can manufacture the following effects: relief, shadow, embossment and so on.
Description Parameter
X,Y Working Area 1500*3000mm
Z Working Area 200mm
Max feeding height Z Axis 200mm
Table Size 1640*3540mm
Resolution 0.01mm
Lathe Structure Seamless welded steel structure
X,Y Structure
Rack and pinion transmission,
Hiwin square guide rail
Z Structure
Taiwan-made rolling ball screw,
Hiwin square guide rail
Max. Idling Speed 35m/min
Spindle 6.0 KW, optional: 2.2kw, 3kw, 4.5kw
Spindle Rotate Speed 0-18000r/min, variable speed
Working Voltage AC380V/50-60Hz, 3phase
Working Mode Stepper
Driver and Motor Yako stepper driver/ Fuxing 118 stepper motor
Command G code (HPGL,U00,mmg,plt)
Operating System DSP with USB interface
Diameter of cutter φ3.175-φ12.7mm
Cooling Mode Air-cooling
Dust-collect Function Optional
Work-holding By suction also can by clamp
Net Weight 1600KG
Software Type 3, ArtCam, Wentai
Packaging & Delivery
Product Image
About Suzhou Rico Machinery Co., Ltd
RICO, a professional CNC machinery company, who integrated research, development and manufacture. Provide CE approved cnc routers, cnc woodturning lathe, cnc lasers, fiber laser marking machines, cnc plasma cutting machines, cnc spare parts and related products all over the world. Giving more concern on innovation, has built up its R&D system under the support and collaboration of national scaled technical center. Technical innovation and development of new products are under processing continuously.
