FT-1616-8R 4Axis CNC Router Machine with 8 rotary axis
Application:
figure carving ,furniture industry ,decoration industry,semi-finished products of industry equipment,instruments industry,mold industry,handicrafts industry,3D engraving of marble and buddha,advertising industry.
Features:
1,Lathe bed welded with thickness steel tube,processed by temperature tempering and vibrating stress relief to reduce residual stress, ensure excellent stability,not easy to be deformed.
2,DPS stick control system and four axis gang control ,can finish the 3D engraving of the cylinder and tetrahedron.specially used for 3D engraving of figure statue ,European-style furniture and stone statue.
3,Adopts constant power spindle, high precision,low noise,high rotating speed,and goog moving stability,fully displaying the superiority of the machine.
4,Stepper motor drive very suitable for cutting and engraving the heavy stone and solid wood.
5,Y axis is gear rack double drive,greatly improving the cutting force and precision.
6,Be compatible with several software,such as type3, CASTMATE,ARTCAM
Technical parameters
Model
FT-1616-8R
Working area
200(diameter)x1300mm rotary 8pcs
Feeding height
200mm
Repositioning accuracy
0.03mm
Transmission
X by rack,Y and Z by ballscrew Germany
Spindle power
1.5KW X8
Spindle speed
0-24000RMP
Power supply
380V/50-60HZ
Command
G code/mmg/plt/
Cutter diameter
3.175/ 4/ 6/ 12.7
Total weight
Approx. 1800kg
Warranty
1 year
Components
Spindle
Water cooling spindle
Inverter
Taiwan Delta inverter
Controlling system
Ncstudio or DSP
Motor and drive
Japan panasonic servo motor or Taiwan Delta
Guide rail
Taiwan Hiwin linear rail
Optional:custom any size machine
4 Axis CNC Router Machine sample photos
Multi-head 4 axis cnc router machine with 8 rotary axis
