DSP control system , with remote hand controller wood metal cnc router engraving machine cnc 2030 with 3d scanner
Features:
1 , Welded steel structure,big and thick steel square tube can be 10mm thick.
2 , 3kw water cooling spindle(top brand in China),0-24000RPM. Good cooling
effect,low noise and durable life.
3 , DSP control system,with remote hand controller and USB interface,doesn't
need to connect with computer,easy and convenient to operate.
4 , Configured with 20# HIWIN linear rail from Taiwan, more stable and precise.
5 , Helical rack transmission for XY axis,more stable and stronger.
6 , Vacuum and T-slot combined worktable,double use.
Parameter:
X,Y,Z Working Area 2000x3000x200mm
X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
X,Y,Z Repositioning Accuracy ±0.03mm
Table Surface Vacuum and T-slot working table
Frame Welded Structure
X, Y Structure helical rack, Taiwan HIWIN Rail Linear Bearings
Z Structure Taiwan HIWIN Rail Linear Bearings and Ball Screw
Max. Power Consumption (Without Spindle) 3.2Kw
Max. Rapid Travel Rate 33000mm/min
Max. Working Speed 25000mm/min
Spindle Power 3kw water cooling spindle
Spindle Speed 0-24000RPM
Drive Motors YAKO or Lead shine
Working Voltage AC380V/50/60Hz,3PH (Option: 220V)
Command Language G Code
Operating System DSP System (Options: Ncstudio/Mach3 PC Software)
Computer Interface USB
Flash Memory 512M(U Disk)
Collet ER25
X,Y Resolution <0.01mm
Software Compatibility Type3, Artcam Software
Running Environment Temperature 0 - 45 Centigrade
Relative Humidity
30% - 75%
Safety level :
1 , Soft limit switch (Shock absorption pad)
2 , Japanese Omron limit switch
3 , French Schneider electronics
4 , French Schneider rotary safety switch on the control box
5 , Shanghai Cardiff cable, high soft shielding twisted-pair cable, fire-resistant and with
low failure rate, could be bent min 30,000,000 times
Application:
Woodworking: three-dimensional wave board processing, cabinet doors, solid wood do
- ors, wooden craft, paint doors, screens, craft fan window processing, shoe polisher, g
- ame cabinets and panels, mahjong table, computer desk and furniture products, auxi
-l iary processing .
Advertising industry: advertising signs, logo making, acrylic cutting, plastic molding, a
variety of materials advertising the production of decorative products.
Mold Industry: engraving copper, aluminum, iron and other metal molds, as well as ar
- tificial marble, sand, plastic sheeting, PVC pipe, wood and other non-metallic mold.
Other Industry: a variety of large-scale relief sculpture, shadow carving, widely used
in the craft industry.
