Detailed Description
1. Product Description
· Suitable for laser cutting machine, soldering tin, laser marking, carving, cutting and other dust odor treatment.
Performance description
· New LCD display, 10 speed control, real- time display of speed, air volume, negative pressure and other information, filter element saturation sound and light alarm;
· Precise microchip control, high sensitive long-distance remote control, 360 ° dead angle free control within 2 meters, switch, air volume regulation, timing shutdown and other functions;
· Equipped with flame arrester to realize Mars isolation and prevent fire hazards;
· BLDCM, energy saving, high speed, large air volume, large negative pressure, low noise, maintenance free.
· In the design of lower air inlet and upper air exhaust, the large particle dust settles in the filter bag under the action of gravity, and the small particle dust passes through the main filter element along with the air flow, so as to prevent the filter element from blocking too fast.
· The filter element adopts drawer type installation, which is convenient and labor-saving.
· Multi stage high efficiency filtration, up to standard discharge
Standard configuration
·primary filter
· medium efficiency filter
· activated carbon filter
· high efficiency filter
· air inlet at left and right sides (φ 200mm)
· vacuum hose (φ 200mm)
· 5m power line
· remote control Spare parts
· primary filter box
· vacuum hose (φ 200mm)
Spare Parts
· Primary filter box
·Vacuum hose (dia. 120mm)
Recommended working condition
· Multifunctional laser cutting machine
· Soldering of circuit board
· Purification of peculiar smell and smoke from acrylic, PVC, rubber and leather materials by laser cutting
2. Technical Parameters
MLWF100
MLWF360
Motor Power
1.5KW
2.2KW
Air Volume
0~700m^3/h
0~1400m^3/h
Working Voltage
220V 50Hz
220V 50Hz
Filtering Accuracy
o.3um
o.3um
Noise Level
70dBA
75dBA
Dimension
640*680*1290mm
840*800*1600mm
Weight
95kg
135kg
